Slim Floor Beams Uk

Deltabeam slim floor structures technical manual 08 2014 deltabeam technical information deltabeam is designed to be used as a structural element combined with all general concrete slab types.

Slim floor beams uk. Since deltabeam is often utilized to support prestressed hollow core slabs the spans perpendicular to the beam can even go beyond 14 meters. Nowadays thanks to the composite slim floor beam cosfb development spans up to 12m and even 14m are possible and the beam remains. It enables the usage of shallow element structures and strengthens the frame structure inside the slab. Deltabeam can have a fire class rating as high as 4 hours.

The beam has been successfully utilised in the uk ireland and further afield since 2006 across a diverse range of sectors. A slimflor beam is a fabrication typically consisting of a column section up to 305ukc with a 15mm plate fig 1. Within the eu all beams have the ce marking sticker. The slim floor beams which are partly contained within the floor slab.

There is an increasing interest in the steel concrete composite slim floor construction in the nordic countries and the uk. A floor layout with less columns allows for floor plans to easily be changed to meet the varying needs of tenants throughout the lifecycle of the building. Significant performance increase of slim floor construction is achieved by an innovative and very economic activation of the in situ concrete for the section properties. By integrating the structure floor to floor depths can be typically reduced by 300mm and when multiplied by the number of storeys of a modest building this leads to significant savings on cladding costs.

Hollow core slab filigran slabs composite steel decking trapezoidal steel decking slabs and cast in situ concrete slabs. Deltabeam slim floor structure and its long spans allow you to create open spaces with grids of up to 12 x 16 meters. In the past beam spans were economically limited to 7m. Deltabeam is designed to be used as a structural element combined with all general concrete slab types.

The long spans in both directions mean less columns are needed. Deltabeam must be lifted using the lifting holes on the top plate. The weight of each deltabeam is displayed on the product sticker on the beam or in the fabrication drawings. Asbs making them more accessible than ever before with a shorter production time and improved availability.

Deltabeam can be lifted and moved using ordinary lifting equipment such as cranes or forklifts. Deltabeam slim floor structure and its long spans allow you to create open spaces with grids of up to 12 x 16 meters. The need for the structural steelwork industry to develop an economical flat slab flooring system led kloeckner metals uk westok to develop the patented and innovative usfb ultra shallow floor beam. The holes are placed symmetrically to.

Tata steel has relaunched its responsibly sourced asymmetric slimflor beams.
